Product Category:[CAT5E Cable]

  • Product Name:unshielded and shielded cat5e utp network cable
  • Product Details:1.data pass100-200m 2.CU,BC 3.CE ROHS ISO Pass 4. oem
    • Contact Supplier:sales9@brothres-ycable.net
    • Conductor material:BC
    • Conductor size:24AWG,26AWG,28AWG
    • Rated temperature::-20℃ ~ 70℃
    • Installation temperature::-20℃ ~ 70℃
    • Minimum bending radius:40
    • Payment Terms:T/T payment

Products Information

Product Name: Lan Cable / Network Cable CAT5e UTP

Executive standard: YD/T1019-2001; ANSI/ EIA/ TIA-568-B.2-2001; ISO/ IEC11801

conductor 99.99% bare copper
size:0.511mm
insulation material: HDPE
diameter:0.92±0.05mm
rip cord material: Nylon
jacket material:PVC
diameter:5.0±0.20mm
color: optional
packing 305m/a box, two box/one carton
testing  pass fluke channel testing
rated temperatuer 60 degree
rated voltage 30V



Application:

*100 Base-T4

*100 Base-TX

*100VG-AnyLAN

*1000 Base-T(Gigabit Ethernet)

*155 Mbps ATM

*622 Mbps ATM



Compliance with:

*ISO/IEC 11801

*TIA/EIA-568-8.2

*IEC-60332-1

*UL 444 (CM/CMR/CMP grade)*RoHS



Electronic Characters
Frequency     MHZ  Attenuation   db/100 m NEXT pr/pr      db ACR   db/100m P.Sum NEXT      db EL-FEXT pr/pr     db/100m PS  EL-FEXT      db/100m RL     db
1.0 2.0 65.3 63.3 62.3 63.8 60.8 20.0
4.0 4.1 56.3 52.0 53.3 51.7 48.7 23.0
10.0 6.5 50.3 44.0 47.3 43.8 40.8 25.0
16.0 8.2 47.3 39.0 44.4 39.7 36.7 25.0
20.0 9.3 45.8 37.0 42.8 37.7 34.7 25.0
31.25 11.7 42.9 31.0 39.9 33.9 30.9 23.6
62.5 17.0 38.4 21.0 35.4 27.8 24.8 21.5
100.0 22.0 35.3 13.0 32.3 23.8 20.8 20.1



Founded in 2002, Shenzhen Brother Young Development Co., Ltd. enjoys a history of 10 years' development and has been upholding the philosophy of "sincere service and quality first", which wins a good reputation in this line of business; After 10 years of constant effort and persistence, it has developed into a modern high-tech enterprise which integrates scientific research, manufacturing, and marketing. Our main products are high-tech cable, including CAT5E and CAT6 network cable, coax cable, optic fiber, multi pair telephone cable, other relative network accessories.



Brothers Young



At present, our products are mainly exported to European and American. Our headquarter is in Wulian Community in Longgang of Shenzhen with a strong team. We own two factories in Jiexi city and Shenzhen city in Guangdong Province respectively. The factories cover an area of nearly 10,000 square meters. At present, our main brand is: brothers-Y. We have introduced advanced production line in factories, and to satisfy the market demand, our products vary from high and medium to low class for the customers to choose from. Over the years, Shenzhen Brothers Young Development Co., LTD has won high praise and trust from customers both at home and abroad with its superior quality, competitive price and sincere service. Our products have got authentication from multiple quality systems such as ISO9001:2008 and UL, ROSH. In 2010. our company was appraised one of top ten advisory of Shenzhen by Alibaba. We always adhere to the "high standard, high requirement" for product requirements, strict in each link of production; ensure the quality of company product reach the advanced level of the industry; Brother Young sincerely welcome friends visit, look forward to your cooperation!



In July, 2006, brothers-Y Network Cable has become the only supplier for SHENZHEN TELECOM.
In September, 2006, brothers-Y Coaxial cable has become one of qualified suppliers for CHINA BROADCASING AND TV.
In 2008, brothers-Y big pairs cable, like 50 pairs, 100 pairs,200pairs,telephone cable have successfully entered into CHINA TELECOM supplier.
From 2009 to 2010, brothers-Y has been a successful cable supplier for HUAWEI, FOXCONN, CITIC, CHINA UNICOM, CHINA MOBILE, and other famous enterprises etc.
